1756-EN2TR EtherNet/IP Module

1756-EN2TR EtherNet/IP Module

1756-EN2TR Specification

Product Type:EtherNet/IP Module
Model Number:1756-EN2TR
Brand: PLC module
Backplane Current (5 Volts): 1 amp
Ethernet-IP Communication Rate: 10/100 Mbps
Backplane Current (24 Volts): 3 milliamps
Integrated Ports: Two (2) RJ45; One (1) USB 1.1
Power Consumption: 5.1 Watts
Current Draw: 1.2 Amp
Insulation Voltage: 30 Volts Continuous
Location: Chassis (any slot)
Enclosure: Open
Slot Width: 1
Operating Temperature: 32 to 140°F (0 to 60°C)
Current Rating: 1.2 Amps
Power Dissipation: 5.1 W
Thermal Dissipation: 21.28 BTU per hour
Communication: Ethernet/IP
Dimensions:3.5x14x14.5cm
Weight:0.36kg

1756-EN2TR Description

The 1756-EN2TR is a part of the Communication Module series. It is an

Ethernet/IP (Ethernet Industrial Protocol) dual port interface communication

module. It supports general messaging, real-time I/O messaging, and information

exchange for applications like Real-Time Control, Time Synchronization, and

Motion. The 1756-EN2TR also meets the CIP safety standard by allowing

simultaneous transfer of safety and control data and diagnostics information.

It uses advanced communication chips and physical media.

The 1756-EN2TR Module has 10 - 100 Mbps Ethernet/IP communication rates

and uses dual copper. It supports 256 128 TCP/IP communication connections. It

can support a maximum of 8 axes for integrated motion on the Ethernet/IP Network

and draws 1 A current at 5.1V DC. It has a maximum power dissipation of 5.1 W

and thermal dissipation of 17.4 BTU/hr. It can be installed in any slot in the Chassis.

For wiring, it uses unshielded RJ45, category 5, twisted-pair cable connectors to

interface with the controller. To operate an Ethernet/IP network, parameters such

as IP addresses, Subnet masks, Gateway, etc. must be defined.

The 1756-EN2TR bridge has various functions like providing support for

messaging, distributed I/O, and tags. It encapsulates messages within standard

TCP/IP protocol. ControlNet and DeviceNet network protocols allow it to share a

common application layer. The 1756-EN2TR does not require any scheduling or

routing table to store information. Other features include explicit protected mode,

Electronic keying, Device Level Ring Network, and Parallel Redundancy Protocol

Network support.

The 1756-EN2TR is a Ethernet Communication module that is especially designed

for use in redundant Ethernet networks. Through the embedded dual RJ545 ports

that supports Ethernet protocol and 10/100 Mbps transmission speed with

auto-negotiation function, this module increases the availability of an Ethernet network.

This module supports Ring and Star topology with qualified partner devices such as

Flex IO, POINT IO Redundant Ethernet adapters, as well. This module also

supports implementing messages to other controllers such as SLC 500, PLC-5,

and controllers. It is also compatible for communicating with Human Machine

Interfaces (HMI), Supervisory Control and Data Acquisition (SCADA) of the

same even, 3rd party products. It may also be partnered with encompass partner

modules and 3rd party gateways, converters and devices.

This module also supports embedded Ethernet communication of computers

and programming workstation thus, there is no need to purchase expensive

communication adapters to establish connection to the controller. Additionally,

the required cable for this module is a Category 5 or 6 cable which can be fabricated

to form the communication cable.
