1769-IF8 Analog Input Module

1769-IF8 Analog Input Module

1769-IF8 Specification

Part Number/Catalog No.:1769-IF8
Module Type:Analog Input Module
Input Type:Analog Input
Communication Cable:8 Point
Power Supply Distance rating:8
Shipping Weight:2 pounds
Input current range:0-21 mA
Current signal normal ranges:0-20mA;  4-20 mA

1769-IF8 Description

   The 1769-IF8 compact I/O analog input module by is an analog input module

with Eight (8) differential inputs and a voltage range of +/-10 Volts DC, 0 to 10

Volts DC, 0 to 5 Volts DC, and 1 to 5 Volts DC, and current range of 0 to 20 mA,

and 4 to 0 mA.

   The 1769-IF8 is a Compact I/O module that is manufactured by in compatibility

with 1769  Controller and 1500 controllers.  This controller features an embedded

Eight (8) Input channels that support differential and single-ended wiring.

Configurable signals are 0-20 mA and 4-20mA and +/10VDC, 1-5VDC, 0-5VDC,

0-10VDC.

   The Analog signal that is received by the input channels are individually converted

using Delta-Sigma conversion method.  The converted signal is stored within the

processor’s memory occupying 16 bits for unipolar and 15 bits for bipolar.  Within

the register are array of binary bits that represent the value of the input signal.  To

properly display the equivalent measurement or engineering values, the data is

used conditioned using a Scale instruction.  The data processed can be configured

as engineering units, scaled for PID, percent range and raw data.

   The power supply distance rating of 1769-IF8 is 8 modules.  This refers to the

physical module location which means it must not be installed 8 modules away from

the 1769 power supply.  This power supply distance rating ensures that the module

will receive the appropriate backplane power.
