330130-040-00-00 Bently Nevada Extension Cable

330130-040-00-00 Bently Nevada Extension Cable

330130-040-00-00 Bently Nevada Specification

Manufacturer : Bently Nevada
Product No. : 330130-040-00-00
Product type : 3300 XL Standard Extension Cable
Cable length option : 040 = 4.0 metres (13.1 feet)
Connector protector and cable option : 00 = Standard cable
Agency approval option : 00 = Not required
Weight : 0.14 Kg

330130-040-00-00 Bently Nevada Description

330130-040-00-00 is a 3300 XL Standard Extension Cable manufactured by Bently Nevada.

Additionally, the 3300 XL probe and extension cable represent advancements over earlier models.

The bond between the probe tip and the probe body is stronger thanks to the proprietary TipLoc

molding process. For a more secure connection between the probe cable and probe tip, the probe's

cable features a unique CableLoc design that offers 330 N (75 lbf) of pull strength.

3300 XL 8 mm probes and extension cables with a FluidLoc cable option stop oil and other liquids

from leaking out of the machine. ClickLoc connectors with corrosion-resistant gold plating are used

on the 3300 XL probe, extension cable, and Proximity sensor. These connections can be finger-tightened

to a certain degree (they will "click" when tight) and are locked in place by a specifically designed locking

mechanism. For installation or removal, these connectors don't need any specialized equipment.
The 3300 XL 8mm Proximity Transducer System from GE / Bently Nevada includes one 8mm probe, one

extension cable, and one Proximitor Sensor. The system measures both static (position) and dynamic (vibration) measurements and gives an output voltage that is directly proportional to the distance between the

probe tip and the observed conductive surface.
Vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and

speed measurements, are the system's principal applications. Standard 3300 XL 8 mm 5-meter system

also completely complies with the API 670 Standard (4th Edition) in terms of mechanical configuration,

linear range, accuracy, and temperature stability. This level of performance is provided by all 3300 XL 8

mm proximity transducer systems.
