BENTLY NEVADA 330851-02-000-080-50-00-05 Proximity Probe

BENTLY NEVADA 330851-02-000-080-50-00-05 Proximity Probe

BENTLY NEVADA 330851-02-000-080-50-00-05 Specification

Manufacturer:BENTLY NEVADA
Model:330851-02-000-080-50-00-05
Product Type:Proximity Probe
Linear Range: 12.7 mm (500 mils)
Operating Temperature: Up to 200°C (392°F), intermittent up to 250°C (482°F)
Material: AISI 4140 steel
Output Signal: 0.787 V/mm (20 mV/mil)
Power Supply: -17.5 Vdc to -26 Vdc
Seals: Front and rear seals with FluidLoc cable for moisture protection
Connectors: High-temperature ClickLoc connectors
Maximum Torque: 0.565 N•m (5 in•lb)
Minimum Bend Radius: 25.4 mm (1.0 in)

BENTLY NEVADA 330851-02-000-080-50-00-05 Description

The 3300 XL 25 mm Proximitor Sensor incorporates the advanced features of previous

3300 XL models, offering a slim design that allows for versatile mounting options,

including high-density DIN-rail installations or traditional panel mount

configurations. Enhanced RFI/EMI immunity ensures the sensor meets European

CE mark approvals without requiring special mounting, while protecting the system

from interference caused by nearby high-frequency radio signals. The sensor is

equipped with SpringLoc terminal strips, which require no special tools for installation

and enable faster, secure, and reliable field wiring connections.

The 3300 XL 25 mm probe is available in a wide range of case configurations, allowing

it to replace standard 7200 25 mm, 7200 35 mm, and 25 mm DE Integral transducer

systems (including both side and rear exit probes). The Proximitor Sensor offers an

output identical to that of the 7200 and 25 mm DE Integral systems, enabling an

easy upgrade without requiring any changes to the existing monitor configuration.

However, when upgrading, all components of the transducer system—including the

probe, extension cable, and Proximitor Sensor—must be replaced with the 3300 XL

25 mm components.
