Bently Nevada 991-25-50-02-05 991 Thrust Transmitter

Bently Nevada 991-25-50-02-05 991 Thrust Transmitter

Bently Nevada 991-25-50-02-05 Specification

A: Full-scale Option
06 0.6-0-0.6 mm
25 25-0-25 mils

B: System Length Option
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)

C: Mounting Option
01 35 mm DIN-rail clips
02 Bulkhead screws
03 DIN clips and screws

D: Agency Approval Option
00 Not required
01 CSA Division 2
05
CSA Division 2, ATEX Zone 0, ATEX
Zone 2 and includes ABS
maritime approval

Bently Nevada 991-25-50-02-05 Description

The 991-25-50-02-05 991 Thrust Transmitter is intended primarily for the original equipment

manufacturers (OEMs) of centrifugal air compressors or small pumps, motors, or fans who

prefer to provide a simple 4 to 20 mA proportional axial displacement (thrust) signal as the

input to their machinery control system. The transmitter is a 2-wire, loop-powered device that

accepts input from our 3300 NSv* proximity probe and its matching extension cable

(available in 5 m and 7 m system length options). The transmitter conditions the signal into

appropriate engineering units proportional to the shaft’s axial position1, and provides it as a

4 to 20 mA industry-standard signal for input to the control system where machinery protection

alarming and logic occurs.

The 991-25-50-02-05 991 transmitter provides the following notable features:
-Integrated Proximitor* Sensor requires no external unit
-Non-isolated “PROX OUT " and "COM" terminals plus a coaxial connector provide a dynamic

vibration and gap voltage signal output for diagnostics3.
-Non-interacting zero and span potentiometers under the Transmitter label supports loop adjustment.
-Test Input pin allows quick verification of loop signal output, using a variable DC voltage source as the input.
-A Power-up Inhibit circuit eliminates signal errors due to line voltage transients.
-A Not OK/Signal Defeat circuit prevents high outputs or false alarms due to a faulty proximity probe

or loose connection.
-Choice of DIN-rail clips or bulkhead mounting screws as standard options simplifies mounting.
-Potted construction for high humidity (up to 100% condensing) environments.
-Compatibility with 3300 NSv proximity probe allows transducer installation in small areas with minimal

clearance, typical of centrifugal air compressors.
