CBI21 ABB Binary input module
CBI21 ABB Description
Features / Applications
• 32 binary inputs divided into two groups each with 16 inputs
• Process current circuits in accordance with EN 50020 with type of protection EEx ib IIC
• Combined installation possible with "Non-Ex-modules" in one module sub-rack
• Signal recording with 1 ms time resolution
• Monitoring of module
• Central galvanic separation of system inputs
• Group-set filter time
• Module is capable of redundancy
CBI21 ABB Specifications
Supply Voltage (UVG): 8 to 9 V (8.2 V typical, according to DIN 19234)
Input Resistance (RE): 1 kΩ
Input Rated Current (Ir): 3 mA
Signal Input Level (-High-): 2.2 to 6.5 mA
Signal Input Level (-Low-): 0.4 to 1 mA
High/Low Threshold (IH/IL): 1.6 mA
Breaking Threshold (IeBreak): 0.2 mA
Galvanic Separation: Central
Measuring Voltage: 250 Veff
Voltage Testing: 1500 Veff (to the system in accordance with EN 50020)
Max. Input Voltage: 12 VDC
