General Electric IS220PTURH1A Primary Turbine Protection Pack

General Electric IS220PTURH1A Primary Turbine Protection Pack

General Electric IS220PTURH1A specification

Part Number: IS220PTURH1A
Manufacturer: General Electric
Series: Mark VIe
Function: I/O PACK

General Electric IS220PTURH1A description

IS220PTURH1A is a Primary Turbine Specific Primary Trip Pack and is part of

the General Electric Speedtronic Mark VIe gas turbine control. This component

connects a turbine control terminal board to one or two Ethernet networks via

an electrical interface. This pack's outputs are routed through a DC-62 pin connection

that connects to a terminal board. The IS220PTURH1A has a black outside shell

with air circulation holes. This case contains various LED indicators on the front,

as well as an IR receiver (infrared port.) This bundle does not use this port.

A CPU board, a second board dedicated to turbine control, and an analog acquisition

auxiliary board are all housed within this case.
The TTURH1C terminal board is used to mount the pack. Two 10/100 Ethernet ports,

flash memory, RAM, a read-only chip for identification, an internal temperature sensor,

and a reset circuit are all on the processor board.
Auto-reconfiguration is available on the IS220PTURH1A, which will automatically

download from the controller to the I/O pack. Baseload, bootloader, firmware, and

settings are all reconfigured. This can only happen if auto-reconfiguration is enabled.

The Component Editor in the Toolbox ST program can enable or disable this.
The IS220PTURH1A features four magnetic speed inputs that are passive. The circuit

sensitivity can detect a 2-RPM turning gear speed to see if the turbine has ceased

spinning (turbine has stopped.) The pack's median speed signal is used for speed

control as well as the principal Overspeed trip signal.
