General Electric IS220PRTDH1A Resistance Temperature Device Input Module

General Electric IS220PRTDH1A Resistance Temperature Device Input Module

General Electric IS220PRTDH1A Specification

Part Number: IS220PRTDH1A
Manufacturer: General Electric
Series: Mark VIe
Product Type: Input Module
Number of Channels: 8
A/D Converter Resolution: 14-bit
Common Mode Voltage Range: ±5 Volts
Maximum Lead Resistance: 15 Ω maximum
Availability: In Stock
Country/Region of Manufacture: United States(USA)
Manual: GEH-6721L

General Electric IS220PRTDH1A Description

IS220PRTDH1A is a Resistance Temperature Device Input Module manufactured and designed by General Electric as part of the Mark VIe Series used in distributed control systems. An RTD input terminal board and one or more I/O Ethernet networks are connected electrically by the Resistance Temperature Device (RTD) Input (PRTD) pack. An acquisition board dedicated to the thermocouple input function is included in the pack, along with a processor board that is shared by all Mark VIe distributed I/O packs. Up to eight RTD inputs can be supported by the I/O pack, while the TRTD terminal boards can support up to sixteen RTD inputs. A DC-37 pin connector that links directly to the terminal board connector for the pack, as well as a three-pin power input, are used for input. There are two RJ45 Ethernet connectors for the output. Indicator LEDs are used to display visual diagnostics.
